Описание

Tapered Roller Подшипник

Taper roller bearing can be submitted to the combined load from both radial and axial, axial load capacity is depending on the Контакт angle, more Контакт area more axial load capacity.

Taper roller bearing can be separated by single row, double rows and four rows, the clearance of single row taper roller bearing have to be Отрегулированный by the customer during mounting, and the clearance of double rows and four rows bearings can be specified by customer and do not need adjustment by customer.

Taper roller bearing is apply of auto mobile, milling, mining metallurgy and plastic segmen

Подшипник No.	Размеры [mm]						Вес [kg]
	d	D	B	C	T	a
15103/15245	26,157	62,000	20,638	14,288	19,050	5,80	0,29
2682/2630	26,162	63,100	25,433	19,050	23,812	9,40	0,38
2682/2631	26,162	66,421	25,433	19,050	23,812	9,40	0,43
1987/1932	26,975	58,738	19,355	15,080	19,050	5,80	0,24
L44649/10	26,988	50,292	14,732	10,668	14,224	3,30	0,11
15580/15523	26,988	60,325	17,462	15,875	19,842	5,10	0,25
15106/15245	26,988	62,000	20,638	14,288	19,050	5,80	0,28
2688/2631	26,988	66,421	25,433	19,050	23,812	9,40	0,42
J15585/20	28,000	57,150	17,462	13,495	17,462	5,10	0,21
1985/1930	28,575	56,896	19,355	15,875	19,845	5,80	0,21
15590/15520	28,575	57,150	17,462	13,495	17,462	5,10	0,19
1988/1922	28,575	57,150	19,355	15,875	19,845	5,80	0,17
1985/1932	28,575	58,738	19,355	15,080	19,050	5,80	0,22
1988/1932	28,575	58,738	19,355	15,080	19,050	5,80	0,22
15590/15523	28,575	60,325	17,462	15,875	19,842	5,10	0,25
1985/1931	28,575	60,325	19,355	15,875	19,845	5,80	0,25
15112/15245	28,575	62,000	20,638	14,288	19,050	5,80	0,27
15113/15245	28,575	62,000	20,638	14,288	19,050	5,80	0,27
M86647/10	28,575	64,292	21,433	16,670	21,433	3,30	0,34
2689/2631	28,575	66,421	25,433	19,050	23,812	9,40	0,41
02474/02420	28,575	68,262	22,225	17,462	22,225	5,10	0,4
2474/2420	28,575	68,262	23,812	17,462	22,225	6,60	0,41
2578/2523	28,575	69,850	25,357	19,050	23,812	8,60	0,47
26112/26283	28,575	72,000	18,923	15,875	19,000	4,10	0,38
26112/26283S	28,575	72,000	18,923	15,875	19,000	4,10	0,38
41125/41286	28,575	72,626	24,257	17,462	24,608	4,10	0,46
41126/41286	28,575	72,626	24,257	17,462	24,608	4,10	0,46
3192/3120	28,575	72,626	29,997	23,812	30,162	10,20	0,61
3198/3120	28,575	72,626	29,997	23,812	30,162	10,20	0,61
3198/3130	28,575	72,626	29,997	23,812	30,162	10,20	0,62
02872/02820	28,575	73,025	22,225	17,462	22,225	3,80	1,04
43112/43312	28,575	79,375	24,074	17,462	25,400	2,00	0,6
L45449/10	29,000	50,292	14,732	10,668	14,224	3,30	0,11
2690/2631	29,367	66,421	25,433	19,050	23,812	9,40	0,4
17118/17244	29,987	62,000	16,566	14,288	16,002	3,60	0,22
15117/15245	29,987	62,000	20,638	14,288	19,050	5,80	0,26
14117A/14276	30,000	69,012	19,583	15,875	19,845	4,30	0,36
JHM88540/13	30,000	72,000	27,783	23,020	29,370	5,60	0,61
15116/15245	30,112	62,000	20,638	14,288	19,050	5,80	0,26
17119/17244	30,162	62,000	16,566	14,288	16,002	3,60	0,23
M86649/10	30,162	64,292	21,433	16,670	21,433	3,30	0,33
M88043/10	30,162	68,262	22,225	17,462	22,225	2,80	0,41
3187/3120	30,162	72,626	29,997	23,812	30,162	10,20	0,59
2558/2523	30,163	69,850	25,357	19,050	23,812	8,60	0,46
15118/15245	30,213	62,000	20,638	14,288	19,050	5,80	0,26
15119/15245	30,213	62,000	20,638	14,288	19,050	5,80	0,26
15120/15245	30,213	62,000	20,638	14,288	19,050	5,80	0,26
14116/14274	30,226	69,012	19,583	15,875	19,845	4,30	0,35
14116/14276	30,226	69,012	19,583	15,875	19,845	4,30	0,36
14116/14283	30,226	72,085	19,583	18,415	22,385	4,30	0,44
M86648A/10	30,955	64,292	21,433	16,670	21,433	3,30	0,32
08125/08231	31,750	58,738	15,080	10,716	14,684	1,30	0,16
LM67048/10	31,750	59,131	16,764	11,811	15,875	3,00	0,17
15123/15245	31,750	62,000	19,050	14,288	18,161	4,80	0,23
15125/15245	31,750	62,000	20,638	14,288	19,050	5,80	0,24
15126/15245	31,750	62,000	20,638	14,288	19,050	5,80	0,25
2580/2520	31,750	66,421	25,357	20,638	25,400	8,60	0,39
M88046/10	31,750	68,262	22,225	17,462	22,225	2,80	0,4
02475/02420	31,750	68,262	22,225	17,462	22,225	5,10	0,37
02476/02420	31,750	68,262	22,225	17,462	22,225	5,10	0,38
23491/23420	31,750	68,262	26,988	22,225	26,988	8,60	0,49
14124/14276	31,750	69,012	19,583	15,875	19,845	4,30	0,35
14125A/14276	31,750	69,012	19,583	15,875	19,845	4,30	0,34
2580/2523	31,750	69,850	25,357	19,050	23,812	8,60	0,44
2580/2523S	31,750	69,850	25,357	19,050	23,812	8,60	0,44
2582/2523	31,750	69,850	25,357	19,050	23,812	8,60	0,44
3188/3120	31,750	72,626	29,997	23,812	30,162	10,20	0,58
3188S/3120	31,750	72,626	29,997	23,812	30,162	10,20	0,59
3193/3120	31,750	72,626	29,997	23,812	30,162	10,20	0,57
02875/02820	31,750	73,025	22,225	17,462	22,225	3,80	0,44
02876/02820	31,750	73,025	22,225	17,462 Похожие продукты Скважинный инструмент API One Piece Келли Клапаны 5000\10000\15000psi Подробнее Скважинный инструмент Стабилизатор Подробнее Скважинный инструмент API 7K Rotary and vibrator hoses Подробнее Скважинный инструмент Cylindrical Roller Подшипник Подробнее CAMTOP Naft — сертифицированный производитель нефтегазового оборудования API 6A / 16A / 16C. Все права защищены.
